UA33D UYIGAO

UA33D UYIGAO

Specifications:

• Brand Name: UYIGAO
• Color: Black
• Material: ABS
• Display: LCD Display with Backlight, 5999 digits(3 5/6)
• Range Control: Auto Range
• Screen Size: 61 * 39mm / 2.4 * 1.5in
• DC Voltage Range: 600mV/6V/60V/600V/1000V
• DC Voltage Resolution: 0.1mV/0.001V/0.01V/0.1V/1V
• AC Voltage Range: 600mV/6V/60V/600V/750V
• AC Voltage Resolution: 0.1mV/0.001V/0.01V/0.1V/1V
• DC Current Range: 60μA/600μA/6000μA/60mA/600mA/20A
• DC Current Resolution: 0.01uA/0.1μA/1μA/0.01mA/0.1mA/0.01A
• AC Current Range: 60μA/600μA/6000μA/60mA/600mA/20A
• AC Current Resolution: 0.01uA/0.1μA/1μA/0.01mA/0.1mA/0.01A
• Frequency Range: 9.999Hz/99.99Hz/999.9Hz/9.999KHz/99.99KHz/999.9KHz/9.999MHz
• Frequency Resolution: 0.001Hz/0.01Hz/0.1Hz/0.001KHz/0.01KHz/0.1KHz/0.001MHz
• Resistance Range: 600Ω/6kΩ/60kΩ/600kΩ/6MΩ/60MΩ
• Resistance Resolution: 0.1Ω/0.001kΩ/0.01kΩ/0.1kΩ/0.001MΩ/0.01MΩ
• Capacitance Range: 9.999nF/99.99nF/999.9nF/9.999μF/99.99μF/999.9μF/9.999mF/99.99mF
• Capacitance Resolution: 0.001nF/0.01nF/0.1nF/0.001μF/0.01μF/0.1μF/0.001mF/0.01mF
• Diode Resolution: 0.001V
• Duty Cycle: 0.1 ~ 99.9%
• Temperature Range: -20~1000℃ / -4~1832℉
• Temperature Resolution: 1℃/1℉
• Transistor hFE Test: 0~1000
• Function: DC/AC Voltage Current, Resistance, Battery Voltage Measurement, Data Hold, Backlight, Auto Power off, NCV Test, Continuity Buzzer Test, Over Load Protection, Short-circuit Protection, Diode Test, Transistor(hFE), Capacitance, Frequency, Duty Cycle, Temperature Test, Flashlight
• Sampling Time: about 3 times/second
• Working Temperature/Humidity: 18~28℃, <80%
• Storage Temperature/Humidity: -10~50℃, <70%
• Power Supply: 1 * 9V 6F22 Battery (Not Included)
• Item Size: 190 * 90 * 50mm / 7.5 * 3.5 * 2.0in
• Item Weight: 305g / 10.8oz
• Package Size: 21.5 * 16 * 6.3cm / 8.5 * 6.3 * 2.5in
• Package Weight: 530g / 18.7oz

Package List:

• 1 * Digital Multimeter
• 1 * Pair of Test Probe
• 1 * K-type Thermocouple TP01 Probe
• 1 * User Manual(English)
